Surface Mount 45 Degree
$100.00
Item
surface-mount-45-degree
Only %1 left
ARCHITECTURAL COLLECTION
Description
ESSENCE architectural light channels provide premium, made-to-order, specification grade, high color quality 24VDC linear task and accent lighting solutions. Backed by short lead times and impeccable service, ESSENCE is easy to specify and install.
- Concealed mounting hardware, minimal end cap thickness (0.04” thick)
- Tight LED pitch (Static White 72 LEDs/ft. Warm Dim. 52 LEDs/ft). White Lens eliminates Pixelation for Static White
- Concealed joiner allows individual segments to be joined with minimal shadowing (Field Assembled runs over 8ft)
- Fixtures available in 1-inch increments up to 8 ft (Field Assembled) and up to 50 ft (Factory Assembled), length includes end caps
- Fixtures longer than 8 ft contain multiple equal length segments that are joined in the field
- Standard phase dimming down to 1%, 0–10V dimming down to 0.1%, Lutron Hi-lume EcoSystem down to 0.1%
- Registered CEC appliance database. Can be used to comply with CEC 2019 title 24 part 6
- UL listed Class 2, Damp location
OVERVIEW
ESSENCE architectural light channels provide premium, made-to-order, specification grade, high color quality 24VDC linear task and accent lighting solutions. Backed by short lead times and impeccable service, ESSENCE is easy to specify and install.
- Concealed mounting hardware, minimal end cap thickness (0.04” thick)
- Tight LED pitch (Static White 72 LEDs/ft. Warm Dim. 52 LEDs/ft). White Lens eliminates Pixelation for Static White
- Concealed joiner allows individual segments to be joined with minimal shadowing (Field Assembled runs over 8ft)
- Fixtures available in 1-inch increments up to 8 ft (Field Assembled) and up to 50 ft (Factory Assembled), length includes end caps
- Fixtures longer than 8 ft contain multiple equal length segments that are joined in the field
- Standard phase dimming down to 1%, 0–10V dimming down to 0.1%, Lutron Hi-lume EcoSystem down to 0.1%
- Registered CEC appliance database. Can be used to comply with CEC 2019 title 24 part 6
- UL listed Class 2, Damp location
Configure Surface Mount 45 Degree
| ES45 | ESSENCE Surface Mount 45 Degree |
| U | U-Series |
| P | P-Series |
| D | D-Series |
Whole Numbers Only
| 17 | 170 LM/FT |
| 22 | 225 LM/FT |
| 25 | 250 LM/FT |
| 37 | 375 LM/FT |
| 62 | 625 LM/FT |
| 924 | 2400K |
| 927 | 2700K |
| 930 | 3000K |
| 935 | 3500K |
| 942 | 4200K |
| 9W31 | Warm Dim 3000K-1800K |
| B | Black |
| F | Frosted |
| W | White |
| W | White (Paintable) |
| B | Black |
| A | Satin Aluminum |
| F | Fixed |
| 2 | 2 Feeds |
| 1L | 1 Feed Left |
| 1R | 1 Feed Right |
| B | Back |
| E | End |
| F | Factory Assembled |
| D | Field Assembled |
Wire Management
