Recessed Flanged 0606
$100.00
Item
recessed-flanged-0606
VC ARCHITECTURAL
Description
ESSENCE Recessed Flanged 0606 architectural light channels evoke a modern aesthetic with a low-profile channel that integrates effortlessly into drywall or millwork, complimenting the space while delivering visual comfort.
- Premium Color Quality and Consistency
- U-Series Static White. 1-step color consistency, CRI 97+, R9 95+, Rf 95+, Rg 100
- P-Series Static White. 2-step color consistency, CRI 95+, R9 90+, Rf 90+, Rg 95-105
- Warm Dim. 2-step color consistency, CRI 95+, R9 90+, Rf 90+, Rg 95
- Clean Aesthetic with Minimal Shadowing
- Concealed mounting hardware, minimal end cap thickness (0.04” thick)
- Tight LED pitch (Static White. 72 LEDs/ft. Warm Dim. 52 LEDs/ft). White Lens eliminates Pixelation for Static White
- Concealed joiner allows individual segments to be joined with minimal shadowing
- Ease of Specifying and Installation
- Factory Assembled and Field Assembled options available
- Fixtures available in 1-inch increments up to 50 ft, length includes flange
- Fixtures longer than 8 ft contain multiple equal length segments that are joined in the field
- Includes mechanical Mounting Clips for ceiling and wall mount
- Application Versatility
- Standard phase dimming down to 0.2% and Lutron Hi-lume Ecosystem down to 0.1% and eldoLED 0-10V down to 0.1%
- Registered CEC appliance database. Can be used to comply with CEC 2019 title 24 part 6
- ETL listed Class 2, Damp listed. approved for use in closets and storage spaces per NEC Article 410.16
Download All
Contact your Sales Rep or Click here to learn how to order
Downloads
Back to Top
ESSENCE Recessed Flanged 0606 architectural light channels evoke a modern aesthetic with a low-profile channel that integrates effortlessly into drywall or millwork, complimenting the space while delivering visual comfort.
Configure Recessed Flanged 0606
| ESRF0606 | ESSENCE Surface Mount 0.6"W X 0.6"H |
| U | U-Series |
| P | P-Series |
| D | D-Series |
| 17 | 170 LM/FT |
| 22 | 225 LM/FT |
| 25 | 250 LM/FT |
| 37 | 375 LM/FT |
| 62 | 625 LM/FT |
| 924 | 2400K |
| 927 | 2700K |
| 930 | 3000K |
| 935 | 3500K |
| 942 | 4200K |
| 9W31 | Warm Dim 3000K-1800K |
| B | Black |
| F | Frosted |
| W | White |
| W | White (Paintable) |
| B | Black |
| A | Satin Aluminum |
| D | Drywall |
| M | Millwork |
| 1 | 1 Feed |
| 2 | 2 Feeds |
| E | End |
| F | Factory Assembled |
| D | Field Assembled |
