3" LED Remodel Fixed Non-IC Downlight
$100.00
Item
element-3-led-remodel-fixed-non-ic-downlight
ARCHITECTURAL COLLECTION
Description
The ELEMENT™ 3" Remodel Fixed Downlight blends stunning architectural aesthetics with exceptional performance and brings it to remodel applications with style. The ELEMENT 3" Remodel Fixed Downlight offers premium LED options with Static White and Warm Dim.
- 1-step SDCM
- Interchangeable optics: 10°, 18°, 25°, 40°, 60°
- Flanged die-cast Bevel and Flat trims
- New Construction installation available
- Trims match the ELEMENT 3" platform
OVERVIEW
The ELEMENT™ 3" Remodel Fixed Downlight blends stunning architectural aesthetics with exceptional performance and brings it to remodel applications with style. The ELEMENT 3" Remodel Fixed Downlight offers premium LED options with Static White and Warm Dim.
- 1-step SDCM
- Interchangeable optics: 10°, 18°, 25°, 40°, 60°
- Flanged die-cast Bevel and Flat trims
- New Construction installation available
- Trims match the ELEMENT 3" platform
Configure 3" LED Remodel Fixed Non-IC Downlight
1. Select Housing (Required)
| E3RR | ELEMENT 3" LED Remodel Fixed Non-IC Housing Round |
| E3SR | ELEMENT 3" LED Remodel Fixed Non-IC Housing Square |
| F | Remodel Flanged |
| -LH | High Output, 17W |
| -LO | Low Output, 12W |
| 827 | 80 CRI, 2700K, 1-Step |
| 830 | 80 CRI, 3000K, 1-Step |
| 835 | 80 CRI, 3500K, 1-Step |
| 927 | 90 CRI, 2700K, 1-Step |
| 930 | 90 CRI, 3000K, 1-Step |
| 935 | 90 CRI, 3500K, 1-Step |
| WD | 90 CRI, 3000-1800K, Warm Dim, 2-Step |
| 922 | 90 CRI, 2200K, 2-Step |
| 924 | 90 CRI, 2400K, 2-Step |
| 0 | 10° |
| 1 | 18° |
| 2 | 25° |
| 4 | 40° |
| 6 | 60° |
| 8 | 80° |
| D | Downlight |
| N | Non-IC Airtight |
| Universal Phase/0-10V 1%-120V (Leave Blank) | |
| -277V | Universal Phase/0-10V 1%-277V |
2. Select Trim (Required To Choose One)
| E3R | ELEMENT 3" Trim Round |
| E3S | ELEMENT 3" Trim Square |
| L | Flangeless |
| F | Flanged Up To 1" Ceiling Thickness |
| F15 | Flanged 1.1"-1.5" Ceiling Thickness |
| F20 | Flanged 1.6"-2.0" Ceiling Thickness |
| F25 | Flanged 2.1"-2.5" Ceiling Thickness |
| B | Bevel |
| F | Flat |
| B8 | 80° Bevel |
| -O | No Lens |
| -H | Shower |
| -L | Lensed |
| W | White |
| Z | Antique Bronze |
| B | Black |
| S | Satin Nickel |
